Velodyne Deep Blue 12
Pressurized, precise low frequency for every living ambiance
The Deep Blue Series combines all the benefits of Velodyne Acoustics subwoofers in a living room-friendly format. The frequency response of the front-firing drivers, designed from the ground up, extends deep into the frequency basement for impressive home theater experiences.
The Features
- Quad voice coil provides high efficiency, fast rise times and pulse fidelity with double ferrite magnets
- Enclosed cabinet made of solid MDF material prevents distortion and vibration
- With adjustable level, crossover frequency and phase, the Deep Blue subwoofers can be flexibly adapted to the listening room and existing equipment
- For connectivity, RCA input jacks are provided for the left and right channels, as well as a dedicated subwoofer input with loop-through capability
| Driver | 12″ forward firing |
| Amplifier | Class AB 850 watts dynamic 350 watts RMS power |
| Frequency Response: Overall Frequency Response: (± 3 dB) | 15 – 250 Hz 26 – 140 Hz |
| Low Pass Crossover | 50 Hz to 180 Hz (12 dB/Octave) |
| Phase | 0 / 180 degrees |
| Cabinet Design | MDF Closed Box with 52mm / 2” front Baffle |
| Magnet Structure | Dual ferrite magnet motor |
| Woofer | 12” high excursion double vented basket driver with PP inforced Membrane |
| Voice Coil | Four Layer 2,5″ / 65mm Voicecoil |
| Input | GoldPlated Line in Stereo RCA, LFE in, Nickel Plated Highlevel |
| Output | Gold plated LFE /RCA |
| Power Selector | Off / Auto / On |
| Finishes | Black |
| Dimensions (W/H/D) (includes feet and connectors) | 35 x 37 x 38,8 cm |
| Weight (approx) | 13 kg |
| Shipping Weight (approx) | 14,8 kg |
